Victory sales a lot of compact gas portable generators ranging in capacity from 1.0kVA – 10 kVA to Middle East, South-Central Asia, North America, Europe, Africa and other countries around the world every year. These LPG generators are widely used for a diverse range of needs, such as an emergency power source in the event of a power failure, outdoor construction work, outdoor leisure activities and for disasters and other emergencies. Since the company was found in 1999, we always do the best to improve the quality in order to meet the requirements of various customers. Therefore, Victory LPG series engines emerged as required. It inherits the excellent performance of Victory gasoline engines, which have high reliability, high quality, low emissions, and compact design. LPG engine series of generators that incorporated a super light weight and compact constraction offering low fuel consumption and low noise.Because of its stable performance, energy efficiency and environmental protection, more and more people prefer to use this kind of generator.
Features:
1. OHV design permits low fuel consumption and noise
2. Classical combustion-chamber shape and excellent suction exhaust effect which to improve combustion efficiency
3. Auto decompressing makes starting easy
4. Oil alert automatically shut off the engine
5. Reliable transistorized magneto-ignition system
6. Speedy start, smooth operation and low vibration
7. With the recoil starter which is easy started by a woman
8. With transistor magnet ignition device to ensure the stable perfomance of ignition & low fuel consumption.
Technology
Frequency 50Hz, 3000RPM, Single-phase voltage 220V, 230V, 240V, etc.
Three-phase voltage 380V/220V, 400V/230V, 415V/240V, etc.
Frequency 60Hz, 3600RPM, Single-phase voltage 120V, 127V, 277V, etc.
Three-phase voltage 208V/120V, 220V/127V, 480V/277V, etc.
Power Factor: 1.0
Protection Standard: IP21-IP23
Model of Connection: 1 phase 2 lines, 3 phase 4 lines
Insulation Grade: H
Power Range: 0.6KW-12KW
Starting System: Recoil or Electric
Govern System: Centrifugal Mechanical
Air cleaner: Dual element
Rotor & Stator: 100% Copper wire
Fuel Efficient & High Output Operation: OHV design for increased efficiency and optimal power transfer
Exceotionally Quiet
1. Large capacity, multi-chamber exhaust system
2. Reduced mechanical noise due to light weight, noise-reducing materials
Fuel Tank: 8~10 hours continuous running under full load
Fuel Types: Liquefied Petroleum Gas & Gasoline
2KW~9.5KW 50Hz Gas(LPG) Portable Generator
| Generator | Model : | LPG2500 | LPG6500 | LPG11000 |
| Frequency (Hz) | 50 | 50 | 50 | |
| Rated.AC output (KVA) | 2.0 | 5.0 | 8.5 | |
| Max.AC output (KVA) | 2.3 | 5.5 | 9.5 | |
| Voltage | 110V-240V | 110V-240V | 110V-240V | |
| Phase | Single phase | Single phase | Single phase | |
| D.C. output/V-A | 12/8.3 | 12/8.3 | 12/8.3 | |
| Power factor(cosΦ) | 1.0 | 1.0 | 1.0 | |
| Alternator type | Self-excited,2-pole,single phase | Self-excited,2-pole,single phase | Self-excited,2-pole,single phase | |
| Material of winding | 100% Copper Wire | 100% Copper Wire | 100% Copper Wire | |
| Starting system | Recoil/Electric | Recoil/Electric | Electric | |
| Noice level at 7 M (dBA) | 78 | 84 | 88 | |
| Fuel Tank Capacity (L) | 15 | 25 | 25 | |
| Engine | Engine Model | LPG210 | LPG420 | LPG620 |
| Type | 1-cylinder, 4 stroke, air-cooled, OHV | 1-cylinder, 4 stroke, air-cooled, OHV | 1-cylinder, 4 stroke, air-cooled, OHV | |
| Bore×stroke(mm) | 70*54 | 90*66 | 77*66 | |
| Speed (rpm) | 3000 | 3000 | 3000 | |
| Displacement (cc) | 208 | 389 | 614 | |
| Compression ratio | 8.5：1 | 8.0：1 | 19:01 | |
| Max. Output | 7HP (5.1KW) | 16HP (11.8KW) | 20HP(14.7KW) | |
| Rated Output | 5.5HP(4.0KW) | 11HP(8.1KW) | 17HP (12.5KW) | |
| Max. Torque | 13.2N.m | 26.5N.m | 45N.m | |
| Gasoline Consumption | ≤360g/kw.h | ≤325g/kw.h | ≤230g/kw.h | |
| Lubracation System | Pressure splashed | Pressure splashed | Pressure splashed | |
| Lube oil capacity | 0.6 | 1.4 | 1.5 | |
| Dimensions | Size(LxWxH) | 590*433*483mm | 685*512*550mm | 930*555*710mm |
| Net weight | 39kg | 85kg | 190kg | |
| 20ft Container | 240PCS | 135PCS | 63PCS | |
| 40ft Container | 480PCS | 270PCS | 132PCS | |
| Optional Features | Handle & Wheels | Yes | Yes | Include |
| Three phase volatge | Yes | Yes | Yes |
2.3KW~10.5KW 60Hz Gas(LPG) Portable Generator
| Generator | Model : | LPG2500 | LPG6500 | LPG11000 |
| Frequency (Hz) | 60 | 60 | 60 | |
| Rated.AC output (KVA) | 2.3 | 5.5 | 9.5 | |
| Max.AC output (KVA) | 2.5 | 6.0 | 10.5 | |
| Voltage | 110V-240V | 110V-240V | 110V-240V | |
| Phase | Single phase | Single phase | Single phase | |
| D.C. output/V-A | 12/8.3 | 12/8.3 | 12/8.3 | |
| Power factor(cosΦ) | 1.0 | 1.0 | 1.0 | |
| Alternator type | Self-excited,2-pole,single phase | Self-excited,2-pole,single phase | Self-excited,2-pole,single phase | |
| Material of winding | 100% Copper Wire | 100% Copper Wire | 100% Copper Wire | |
| Starting system | Recoil/Electric | Recoil/Electric | Electric | |
| Noice level at 7 M (dBA) | 78 | 84 | 88 | |
| Fuel Tank Capacity (L) | 15 | 25 | 25 | |
| Engine | Engine Model | LPG210 | LPG420 | LPG620 |
| Type | 1-cylinder, 4 stroke, air-cooled, OHV | 1-cylinder, 4 stroke, air-cooled, OHV | 1-cylinder, 4 stroke, air-cooled, OHV | |
| Bore×stroke(mm) | 70*54 | 90*66 | 77*66 | |
| Speed (rpm) | 3600 | 3600 | 3600 | |
| Displacement (cc) | 208 | 389 | 614 | |
| Compression ratio | 8.5：1 | 8.0：1 | 19:01 | |
| Max. Output | 7HP (5.1KW) | 16HP (11.8KW) | 20HP(14.7KW) | |
| Rated Output | 5.5HP(4.0KW) | 11HP(8.1KW) | 17HP (12.5KW) | |
| Max. Torque | 13.2N.m | 26.5N.m | 45N.m | |
| Gasoline Consumption | ≤360g/kw.h | ≤325g/kw.h | ≤230g/kw.h | |
| Lubracation System | Pressure splashed | Pressure splashed | Pressure splashed | |
| Lube oil capacity | 0.6 | 1.4 | 1.5 | |
| Dimensions | Size(LxWxH) | 590*433*483mm | 685*512*550mm | 930*555*710mm |
| Net weight | 39kg | 85kg | 190kg | |
| 20ft Container | 240PCS | 135PCS | 63PCS | |
| 40ft Container | 480PCS | 270PCS | 132PCS | |
| Optional Features | Handle & Wheels | Yes | Yes | Included |
| Three phase volatge | Yes | Yes | Yes |
